Lincoln Power Wave® C300

Lincoln Power Wave® C300

LK2865-1

Lincoln Power Wave® C300

The Lincoln Electric Power Wave® C300 is a compact, advanced multi-process power source with an integrated wire feeder. It is designed for high‑performance welding across a wide range of materials including aluminium, stainless steel and nickel alloys. Featuring PowerConnect™ auto‑adjusting input, Tribrid™ efficiency and CheckPoint™ cloud monitoring, the C300 delivers precise arc control, portability and durability in an IP23‑rated case.

Enquire Now

Submit an Enquiry

Key Features

  • Multi‑process capability: Stick, DC TIG, Pulsed DC TIG, MIG, Pulsed MIG, Flux‑Cored
  • Integrated wire feeder for compact all‑in‑one operation
  • PowerConnect™ Technology – adapts automatically to 200–600V input
  • Tribrid™ Power Module for high efficiency and power factor
  • CheckPoint™ cloud monitoring and Production Monitoring tools
  • Integrated TIG torch and spool gun solenoid for fast process changeover
  • Rugged IP23‑rated case

Specifications

Processes Stick, DC TIG, Pulsed DC TIG, MIG, Pulsed MIG, Flux‑Cored
Output Range 5–300 A
Rated Output @40% Duty Cycle 300A / 29V
Rated Output @100% Duty Cycle 250A / 27V
Input Voltage 208/220–230/380–415/460/575 V, 1 or 3 Ph, 50/60 Hz
Input Current (3Ph @40%) 30/28/16/14/11 A
Dimensions (mm) H 478 × W 356 × D 697
Weight (kg) 47.6–100  (configuration dependent)
Enclosure Rating IP23
